产品选型
列表中已经列出产品为标准制品，可直接下单订购。可通过右边搜索框对选型表中所有项目的数据进行搜索，如搜索不到您所要的数据，您可以联系我们为您量身定制。
联络我们 »
| 料号 | 产品尺寸 Dimension(mm) | 电流(A) | 耐用性(循环次数) | 工作高度(mm) | 弹簧力(gf) | 图档 | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Part Number | ΦA | ΦB | ΦC | D | E | F | H | Rated Current(A) | Durability(cycle) | Working Height(mm) | Spring Force(gf) | Drawings |
| 060-PGS095-22201-180 | 0.6 | 0.95 | 2 | 0.4 | 1.4 | 0.4 | 1.8 | 1 | 10,000 | 1.5 | 40±20% | |
| 060-PGS095-22201-190 | 0.6 | 0.95 | 2 | 0.5 | 1.5 | 0.4 | 1.9 | 1 | 10,000 | 1.6 | 50±20% | |
| 060-PGS095-22201-200 | 0.6 | 0.95 | 2 | 0.5 | 1.6 | 0.4 | 2 | 1 | 10,000 | 1.7 | 50±20% | |
| 060-PGS095-22201-220 | 0.6 | 0.95 | 2 | 0.5 | 1.7 | 0.5 | 2.2 | 1 | 10,000 | 1.8 | 50±20% | |
| 060-PGS095-22201-235 | 0.6 | 0.95 | 1.5 | 0.3 | 1.75 | 0.6 | 2.35 | 1 | 10,000 | 1.9 | 60±20% | |
| 060-PGS095-22201-240 | 0.6 | 0.95 | 2 | 0.5 | 1.8 | 0.6 | 2.4 | 1 | 10,000 | 2 | 60±20% | |
| 060-PGS095-22201-255 | 0.6 | 0.95 | 2 | 0.5 | 1.9 | 0.65 | 2.55 | 1 | 10,000 | 2.1 | 60±20% | |
| 060-PGS095-22201-270 | 0.6 | 0.95 | 2 | 0.5 | 2 | 0.7 | 2.7 | 1 | 10,000 | 2.15 | 60±20% | |
| 060-PGS095-22201-300 | 0.6 | 0.95 | 2 | 0.5 | 2.1 | 0.9 | 3 | 1 | 10,000 | 2.4 | 50±20% | |
| 080-PGS130-22201-570 | 0.8 | 1.3 | 2 | 0.5 | 4.2 | 1.5 | 5.7 | 2 | 10,000 | 4.7 | 75±20% | |
| 080-PGS130-22201-660 | 0.8 | 1.3 | 2 | 0.5 | 4.6 | 2 | 6.6 | 2 | 10,000 | 5.9 | 160±20% | |
| 090-PGS150-22201-300 | 0.9 | 1.5 | 2 | 0.5 | 2.2 | 0.8 | 3 | 2 | 10,000 | 2.4 | 80±20% | |
| 090-PGS150-22201-320 | 0.9 | 1.5 | 2 | 0.5 | 2.4 | 0.8 | 3.2 | 2 | 10,000 | 2.6 | 80±20% | |
| 090-PGS150-22201-330 | 0.9 | 1.5 | 2 | 0.5 | 2.5 | 0.8 | 3.3 | 2 | 10,000 | 2.7 | 80±20% | |
| 100-PGS150-22201-450 | 1 | 1.5 | 2 | 0.5 | 3.5 | 1 | 4.5 | 2 | 100,000 | 3.9 | 75±20% | |
| Part Number | ΦA | ΦB | ΦC | D | E | F | H | Rated Cyrrent(A) | Durability(cycle) | working height(mm) | Spring Force(grams) | Drawings |
